New X-ray technology can improve Covid-19 diagnosis

12/6/2022
Reading time 3 min.

A research team at the Technical University of Munich (TUM) has, for the first time, produced dark-field X-ray images of patients infected with the corona virus. In contrast to conventional X-ray images, dark-field images visualize the microstructure of the lung tissue, thereby providing additional information. This approach has the potential to provide an alternative to computed tomography (CT), which requires a significantly higher radiation dose.

Franz Pfeiffer, Professor of Biomedical Physics and Director of the Munich Institute of Biomedical Engineering at TUM.

The lungs of Covid-19 patients are normally visualized using computed tomography (CT). CT technology uses multiple X-ray images from different angles to compute a three-dimensional image. This provides more accurate results than two-dimensional imaging using conventional X-ray technology. The downside, however, is a higher radiation dose due to the large number of X-ray images required.

Dark-field chest X-ray is a new X-ray technology developed by Prof. Franz Pfeiffer. It is paving the road for new possibilities in radiological diagnostics: "During our X-ray examination, we take conventional X-ray images and dark-field images simultaneously. This gives us additional information about the affected lung tissue quickly and easily," says Franz Pfeiffer, Professor of Biomedical Physics and Director of the Munich Institute of Biomedical Engineering at TUM.

"The resulting radiation dose is fifty times smaller compared to CT machines. Consequently, this method is promising for application scenarios that require repeated examinations over extended periods of time – for example, when investigating the progression of long covid. This approach might serve as an alternative to computed tomography for imaging lung tissue over prolonged observation periods," Franz Pfeiffer explains further.

Additional information on lung tissue microstructure

In a new study, radiologists compared the images of patients with Covid 19 lung disease to those of healthy individuals. They found that distinguishing between sick and healthy individuals was easier using dark-field images than conventional X-ray images. The radiologists were able to differentiate between diseased and healthy lung tissue most readily when both kinds of images – conventional and darkfield – were available.

Manuela Frank, a lead author of the study.

While conventional X-ray technology relies on the attenuation of X-rays, dark-field X-ray technology utilizes so-called small-angle X-ray scattering. This opens the door to garner additional information on the nature of lung tissue microstructure. Dark-field images can thus provide added value when investigating a variety of lung diseases.

Quantitative evaluation

The research team optimized the X-ray machine prototype to allow them to evaluate the images quantitatively. A healthy lung with many intact alveoli produces a strong dark-field signal and appears bright in the image. In contrast, inflamed lung tissue, with embedded fluid, produces a weaker signal and appears darker in the image. "We normalize the dark-field signal with regard to lung volume to account for lung volume variations between individuals," explains Manuela Frank, a lead author of the paper.

Daniela Pfeiffer, Professor of Radiology and medical director of the study at the TUM University hospital Klinikum rechts der Isar.

"Next, we hope to examine further patients. Once we have sufficient dark-field X-ray data available, we intend to use artificial intelligence to support the evaluation process. For conventional images, we have already carried out a pilot project for AI evaluation of our X-ray images," says Daniela Pfeiffer, professor of radiology and medical director of the study at the TUM University hospital Klinikum rechts der Isar.

Publications

Manuela Frank, Florian T. Gassert, Theresa Urban, Konstantin Willer, Wolfgang Noichl, Rafael Schick, Manuel Schultheiss, Manuel Viermetz, Bernhard Gleich, Fabio De Marco, Julia Herzen, Thomas Koehler, Klaus Jürgen Engel, Bernhard Renger, Felix G. Gassert, Andreas Sauter, Alexander A. Fingerle, Bernhard Haller, Marcus R. Makowski, Daniela Pfeiffer, Franz Pfeiffer. Dark-field chest X-ray imaging for the assessment of COVID-19-pneumonia. Communications Medicine, November 2022. DOI: 10.1038/s43856-022-00215-3

Further information and links

More information on the new dark-field X-ray technology:

Dark-field X-ray is a novel medical examination method. Prof. Franz Pfeiffer and his team developed the method from the ground up and have been advancing it continuously for over ten years, making it available for the world-wide first use in patients.

In close cooperation with radiologists at the TUM University hospital Klinikum rechts der Isar, the researchers developed the dark-field X-ray prototype which has been approved for initial clinical studies. The prototype is currently being used in several studies with patients suffering from various lung diseases. Following an initial study on chronic obstructive pulmonary disease (COPD) and Covid-19, the technology might also be deployed in the future for other lung pathologies such as lung cancer, fibrosis, or pneumothorax.

New technology for clinical CT scans (2022)
New X-ray technology first used with patients (2021)
First use with patients with the lung disease COPD
New X-ray method for Corona diagnosis ready for patient testing (2020)
Planned study with Covid-19 patients
Grating based x-ray dark field imaging
How the method works
Schematic representation (illustration)

Further information:

Prof. Franz Pfeiffer is the Director of the Munich Institute of Biomedical Engineering (MIBE). MIBE is an Integrative Research Institute (IRI) within the Technical University of Munich (TUM). At MIBE, researchers specializing in medicine, the natural sciences, and engineering join forces to develop new methods for diagnosing or treating diseases. They also work on improving technologies that compensate for physical disabilities. The activities cover the entire development process – from the study of basic scientific principles through to their application in new medical devices, medicines and software.

The authors Franz Pfeiffer (TUM), Daniela Pfeiffer (TUM) and Thomas Koehler (Philips Research) are Fellows of the TUM Institute for Advanced Study (TUM-IAS). The TUM-IAS creates interdisciplinary research groups with researchers from TUM and guests from other research institutions and industry to explore new, challenging fields of research.

The work was supported by the European Research Council through a Starting and an Advanced Grant, and by Philips by providing technical components.
